Battery Management System

Implement control strategies for battery management systems (BMS) using controllers, estimators, monitors, and balancers

Simscape™ Battery™ includes Simulink® blocks that perform typical battery management system (BMS) functions, such as state estimation, battery protection, cell balancing, thermal management, and current management. Use these blocks to implement estimation algorithms for battery cell state-of-charge and battery cell state-of-health, simulate battery cell balancing algorithms, size the balancing resistors, get and apply battery charging and discharging limits based on the internal states, simulate battery protection algorithms, and much more. These libraries are fully compatible with the custom battery models that you can generate by using the buildBattery function.
