Power Transmission Using Pulley Networks

Best practices for modelling Simscape™ Driveline™ pulley systems

The Simscape Driveline Couplings and Drives library includes pulley blocks that allow you to transmit power. The Belt Pulley block represents a simple belt-driven friction pulley. The Belt Drive block combines two Belt Pulley blocks that you can configure as an open or crossed belt system. You can model a simple hoist using the Belt Pulley. To model more complex mechanisms, combine several pulley blocks with tensioners, which you build using springs and dampers. Build high-fidelity models by including other Simscape and Simscape Driveline blocks.

Simscape Blocks

Belt Drive	Power transmission system with taut belt connecting two pulleys
Belt Pulley	Power transmission element with frictional belt wrapped around pulley circumference

Topics

Best Practices for Modeling Pulley Networks
Learn about belt direction and using ropes and inertias in pulley networks.
Verify Pulley Configuration in Power Window System
The Simscape Driveline power window example contains a pulley network that uses tension and inertia and follows recommended belt-direction practices.
Troubleshoot Pulley Network Issues
Learn how to solve initialization and motion issues in pulley networks.
