Create and Add Custom Data Elements

Generate an ASAP2 file by adding custom characteristics, measurements, axis-points, functions, groups, record layouts, and CompuMethods. By default, an ASAP2 file contains the data elements present in model that were configured to export.

Using the Simulink® Coder™ you can:

  • Create and add custom data elements such as characteristics, measurements, axis-points, functions, groups, record layouts, and CompuMethods.

  • Remove data elements from the ASAP2 file.

  • Filter and filter data elements based on their properties.

  • Get or update the properties of data elements.

Video - Customization of ASAP2 File

This video walks you through how to build a model and add, update, find, delete custom data elements in an ASAP2 file.

Video Player is loading.
Current Time 0:00
Duration 0:00
Loaded: 0%
Stream Type LIVE
Remaining Time 0:00

1x
  • Chapters
  • descriptions off, selected
  • captions off, selected

      Customize an ASAP2 File

      Add, update, filter, find, and remove ECU descriptions in an ASAP2 file.

      Open and Build Example Model

      Open the example model ASAP2Demo

      open_system("ASAP2Demo");

      Build the model.

      slbuild("ASAP2Demo");
      ### Searching for referenced models in model 'ASAP2Demo'.
      ### Found 1 model reference targets to update.
      ### Starting serial model reference code generation build.
      ### Successfully updated the model reference code generation target for: ASAP2DemoModelRef
      ### Starting build procedure for: ASAP2Demo
      ### Successful completion of build procedure for: ASAP2Demo

      Build Summary

      Model reference code generation targets:

      Model              Build Reason                                 Status                        Build Duration
      ============================================================================================================
      ASAP2DemoModelRef  Target (ASAP2DemoModelRef.c) did not exist.  Code generated and compiled.  0h 0m 28.438s

      Top model targets:

      Model      Build Reason                                         Status                        Build Duration
      ============================================================================================================
      ASAP2Demo  Information cache folder or artifacts were missing.  Code generated and compiled.  0h 0m 43.931s

      2 of 2 models built (0 models already up to date)
      Build duration: 0h 1m 15.078s


      Create the ECU description object for the model.

      descObj = coder.asap2.getEcuDescriptions("ASAP2Demo");

      Get the list of available computation methods in the description object.

      find(descObj,"CompuMethod")
      ans = 1x10 string
          "ASAP2DemoModelRef_CM_double"    "ASAP2DemoModelRef_CM_int16_rpm"    "ASAP2Demo_CM_double"    "ASAP2Demo_CM_double_m_per__s_2_"    "ASAP2Demo_CM_double_rpm"    "ASAP2Demo_CM_int32"    "ASAP2Demo_CM_single"    "ASAP2Demo_CM_single_m_per__s_2_"    "ASAP2Demo_CM_single_rpm"    "ASAP2Demo_CM_uint8"



      Filter the computation methods and get a list of computation methods that use rpm as the unit.

      find(descObj,"CompuMethod",Units='rpm')
      ans = 1x3 string
          "ASAP2DemoModelRef_CM_int16_rpm"    "ASAP2Demo_CM_double_rpm"    "ASAP2Demo_CM_single_rpm"



      Create and Add Custom Computation Method

      To add a new computation method to the ASAP2 file, create a custom computation method.

      CompuMethod_1 = coder.asap2.CompuMethod;
      CompuMethod_1.Name = 'CompuMethod_1';
      CompuMethod_1.ConversionType = 'LINEAR';
      CompuMethod_1.Coefficients = [2 3];
      CompuMethod_1.LongIdentifier = 'longIdentifierTest';
      CompuMethod_1.Format = '%2.3';
      CompuMethod_1.Units = 's';

      Add the custom computation method to the ECU description object.

      add(descObj,CompuMethod_1);

      Get the properties of the newly added computation method.

      get(descObj,"CompuMethod","CompuMethod_1")
      ans =
        CompuMethod with properties:

                     Name: 'CompuMethod_1'
           LongIdentifier: 'longIdentifierTest'
                   Format: '%2.3'
                    Units: 's'
             Coefficients: [2 3]
           ConversionType: 'LINEAR'
          CompuVTabValues: [1x1 struct]
               CustomData: ""



      To modify a property of the computation method, use set function. Update the ConversionType field of the computation method to TAB_VERB and define the CompuVTabValues.

      set(descObj,"CompuMethod","CompuMethod_1",ConversionType="TAB_VERB");
      set(descObj,"CompuMethod","CompuMethod_1",CompuVTabValues = struct('Literals',["false" "true"],'Values',[0 1]));

      Get the properties to see the modified fields.

      modifiedprop = get(descObj,"CompuMethod","CompuMethod_1")
      modifiedprop =
        CompuMethod with properties:

                     Name: 'CompuMethod_1'
           LongIdentifier: 'longIdentifierTest'
                   Format: '%2.3'
                    Units: 's'
             Coefficients: [2 3]
           ConversionType: "TAB_VERB"
          CompuVTabValues: [1x1 struct]
               CustomData: ""


      modifiedprop.CompuVTabValues
      ans = struct with fields:
          Literals: ["false"    "true"]
            Values: [0 1]



      Generate the ASAP2 file using the updated ECU description object and verify that the ASAP2 file contains the computation method CompuMethod_1.

      coder.asap2.export("ASAP2Demo",CustomEcuDescriptions=descObj);
      Following Characteristics or Measurements with unsupported data types are not exported in ASAP2 file. "ASAP2Demo_DW.ASAP2DemoModelRef_InstanceData"


      Delete Computation Method

      Remove the newly added computation method from the description object.

      delete(descObj,"CompuMethod","CompuMethod_1");

      Create and Add Custom Characteristic

      To add a new characteristic to the ASAP2 file, create a custom characteristic.

      Parameter_1 = coder.asap2.Characteristic;
      Parameter_1.Name = 'Custom_parameter1';
      Parameter_1.LongIdentifier = 'longIdentifierParam';
      Parameter_1.UpperLimit = 255;
      Parameter_1.LowerLimit = 0;

      Add the custom characteristic to the ECU description object.

      add(descObj,Parameter_1);

      Get the properties of the newly added characteristic.

      get(descObj,"Characteristic","Custom_parameter1")
      ans =
        Characteristic with properties:

                         Name: 'Custom_parameter1'
               LongIdentifier: 'longIdentifierParam'
                         Type: 'VALUE'
                   EcuAddress: '0x0000'
              CompuMethodName: 'NO_COMPU_METHOD'
                   LowerLimit: 0
                   UpperLimit: 255
            EcuAddressComment: ""
          EcuAddressExtension: []
            CalibrationAccess: 'Calibration'
            DisplayIdentifier: ""
                       Format: ""
                      BitMask: []
                     AxisInfo: []
                 RecordLayout: ""
                   Dimensions: []
                       Export: 1
                   MaxRefresh: [1x1 struct]
                   SymbolLink: [1x1 struct]
                   CustomData: ""



      To modify a property of the characteristic, use set function. Update the UpperLimit field of the characteristic.

      set(descObj,"Characteristic","Custom_parameter1",UpperLimit=128)

      Generate the ASAP2 file using the updated ECU description object and verify that the ASAP2 file contains the characteristic Custom_parameter1.

      coder.asap2.export("ASAP2Demo",CustomEcuDescriptions=descObj);
      Following Characteristics or Measurements with unsupported data types are not exported in ASAP2 file. "ASAP2Demo_DW.ASAP2DemoModelRef_InstanceData"


      Remove the newly added characteristic from the description object.

      delete(descObj,"Characteristic","Custom_parameter1");

      Create and Add Custom Measurement

      To add a new measurement to the ASAP2 file, create a custom measurement.

      Signal_1 = coder.asap2.Measurement;
      Signal_1.Name = 'Custom_signal1';
      Signal_1.LongIdentifier = 'longIdentifierSignal';
      Signal_1.UpperLimit = 255;
      Signal_1.LowerLimit = 0;

      Add the custom measurement to the ECU description object.

      add(descObj,Signal_1);

      Get the properties of the newly added measurement.

      get(descObj,"Measurement","Custom_signal1")
      ans =
        Measurement with properties:

                         Name: 'Custom_signal1'
               LongIdentifier: 'longIdentifierSignal'
                     DataType: 'UBYTE'
                   EcuAddress: '0x0000'
              CompuMethodName: ""
                   LowerLimit: 0
                   UpperLimit: 255
                       Raster: [1x1 struct]
            EcuAddressComment: ""
          EcuAddressExtension: []
            CalibrationAccess: 'NoCalibration'
            DisplayIdentifier: ""
                       Format: ""
                      BitMask: []
                   Dimensions: []
                       Export: 1
                     MaskData: [1x1 struct]
                   MaxRefresh: [1x1 struct]
                   SymbolLink: [1x1 struct]
                   CustomData: ""



      To modify a property of the measurement, use set function. Update the CalibrationAccess field of the measurement.

      set(descObj,"Measurement","Custom_signal1",CalibrationAccess='Calibration')

      Generate the ASAP2 file using the updated ECU description object and verify that the ASAP2 file contains the measurement with name Custom_signal1.

      coder.asap2.export("ASAP2Demo",CustomEcuDescriptions=descObj);
      Following Characteristics or Measurements with unsupported data types are not exported in ASAP2 file. "ASAP2Demo_DW.ASAP2DemoModelRef_InstanceData"


      Remove the newly added measurement from the description object.

      delete(descObj,"Measurement","Custom_signal1");

      Create and Add Lookup Table Parameter

      Add a lookup table parameter.

      LUT_Parameter = coder.asap2.Characteristic;
      LUT_Parameter.Name = "custom_lookup_table";
      LUT_Parameter.Type = "MAP";

      Create and add axis information to the parameter.

      axis_data = coder.asap2.AxisInfo;
      axis_data(1).Name = 'BP3';
      axis_data(2).Name = 'Bp4';
      axis_data(1).CompuMethodName = 'ASAP2Demo_CM_double';
      axis_data(2).CompuMethodName = 'ASAP2Demo_CM_double';
      axis_data(1).MaxAxisPoints = '3';
      axis_data(2).MaxAxisPoints = '3';
      axis_data(1).AxisType = 'STD_AXIS';
      axis_data(2).AxisType = 'STD_AXIS';
      LUT_Parameter.AxisInfo = axis_data;

      Add the lookup table parameter to the description object.

      add(descObj,LUT_Parameter)

      Generate the ASAP2 file using the updated ECU description object and verify that the ASAP2 file contains the lookup table parameter custom_lookup_table.

      coder.asap2.export("ASAP2Demo",CustomEcuDescriptions=descObj);
      Following Characteristics or Measurements with unsupported data types are not exported in ASAP2 file. "ASAP2Demo_DW.ASAP2DemoModelRef_InstanceData"


      Create and Add Custom Group

      Add, update, filter, find, and remove ECU descriptions for groups in an ASAP2 file.

      Open and Build Example Model

      Open the example model ASAP2Demo

      open_system("ASAP2Demo");

      Build the model.

      slbuild("ASAP2Demo");
      ### Searching for referenced models in model 'ASAP2Demo'.
      ### Found 1 model reference targets to update.
      ### Starting serial model reference code generation build.
      ### Successfully updated the model reference code generation target for: ASAP2DemoModelRef
      ### Starting build procedure for: ASAP2Demo
      ### Successful completion of build procedure for: ASAP2Demo

      Build Summary

      Model reference code generation targets:

      Model              Build Reason                                 Status                        Build Duration
      ============================================================================================================
      ASAP2DemoModelRef  Target (ASAP2DemoModelRef.c) did not exist.  Code generated and compiled.  0h 0m 9.0669s

      Top model targets:

      Model      Build Reason                                         Status                        Build Duration
      ============================================================================================================
      ASAP2Demo  Information cache folder or artifacts were missing.  Code generated and compiled.  0h 0m 24.641s

      2 of 2 models built (0 models already up to date)
      Build duration: 0h 0m 36.56s


      Create the ECU description object for the model.

      descObj = coder.asap2.getEcuDescriptions("ASAP2Demo");

      Get the list of available groups in the description object.

      find(descObj,"Group")
      ans = 1x2 string
          "ASAP2Demo"    "ASAP2Demo_ASAP2DemoModelRef_ASAP2DemoModelRef"



      Filter the groups and get a list of groups that has Root set to true.

      find(descObj,"Group",Root=true)
      ans =
      "ASAP2Demo"


      Create and Add Custom Group

      To add a new group to the ASAP2 file, create a custom group.

      GroupObj_GR1 = coder.asap2.Group;
      GroupObj_GR1.Name = 'CustomGroup_1';
      GroupObj_GR1.LongIdentifier = 'New test group';
      GroupObj_GR1.RefCharacteristic = ["ydata3", "ydata4"];
      GroupObj_GR1.RefMeasurement = ["ASAP2Demo_Y.Out3", "ASAP2Demo_Y.Out3"];
      GroupObj_GR1.Root = true;

      Add the custom group to the ECU description object.

      add(descObj,GroupObj_GR1);

      Get Group Properties

      Get the properties of newly added group by using this command.

      get(descObj,"Group","CustomGroup_1")
      ans =
        Group with properties:

                       Name: 'CustomGroup_1'
             LongIdentifier: 'New test group'
          RefCharacteristic: ["ydata3"    "ydata4"]
             RefMeasurement: ["ASAP2Demo_Y.Out3"    "ASAP2Demo_Y.Out3"]
                       Root: 1
                   SubGroup: [1x0 string]
                 CustomData: [1x0 string]



      Update Group Properties

      To modify a property of the group, use set function. Update the LongIdentifier field of the group.

      set(descObj,"Group","CustomGroup_1",LongIdentifier="Group 1 new long identifier")

      Generate the ASAP2 file using the updated ECU description object and verify that the ASAP2 file contains the group CustomGroup_1.

      coder.asap2.export("ASAP2Demo",CustomEcuDescriptions=descObj);
      Following Characteristics or Measurements with unsupported data types are not exported in ASAP2 file. "ASAP2Demo_DW.ASAP2DemoModelRef_InstanceData"


      Delete Group

      Remove the newly added group from the description object.

      delete(descObj,"Group","CustomGroup_1");
