Get Started with HDL Coder

Generate VHDL and Verilog code for FPGA and ASIC designs

HDL Coder™ enables high-level design for FPGAs, SoCs, and ASICs by generating portable, synthesizable Verilog® and VHDL® code from MATLAB® functions, Simulink® models, and Stateflow® charts. You can use the generated HDL code for FPGA programming, ASIC prototyping, and production design.

HDL Coder includes a workflow advisor that automates prototyping generated code on Xilinx®, Intel®, and Microchip boards or generates IP cores for ASIC and FPGA workflows. You can optimize for speed and area, highlight critical paths, and generate resource utilization estimates before synthesis. HDL Coder provides traceability between your Simulink models and the generated Verilog and VHDL code, enabling code verification for high-integrity applications adhering to DO-254 and other standards.

Tutorials

About HDL Code Generation

Featured Examples

Videos

HDL Coder Overview
Generate VHDL and Verilog code for FPGA and ASIC designs using HDL Coder

Using Simulink to Deploy a MATLAB Algorithm on an FPGA or ASIC
Learn how to take a MATLAB DSP algorithm through Simulink, Fixed-Point Designer™, and HDL Coder, and target an FPGA or ASIC
