# Condenser Evaporator (TL-2P)

Models heat exchange between a thermal liquid network and a network that can undergo phase change

*Since R2020b*

**Libraries:**

Simscape /
Fluids /
Fluid Network Interfaces /
Heat Exchangers

## Description

The Condenser Evaporator (TL-2P) block models a heat exchanger with one
thermal liquid network, which flows between ports **A1** and
**B1**, and one two-phase fluid network, which flows between ports
**A2** and **B2**. The heat exchanger can act as a
condenser or as an evaporator. The fluid streams can be aligned in parallel, counter, or
cross-flow configurations.

**Example Heat Exchanger for Refrigeration Applications**

You can model the thermal liquid side as flow within tubes, flow around the two-phase fluid tubing, or by an empirical, generic parameterization.

The block uses the Effectiveness-NTU (E-NTU) method to model heat transfer through the shared wall. Fouling on the exchanger walls, which increases thermal resistance and reduces the heat exchange between the two fluids, is also modeled. You can also optionally model fins on both the thermal liquid and two-phase fluid sides. Pressure loss due to viscous friction on both sides of the exchanger can be modeled analytically or by generic parameterization, which you can use to tune to your own data.

You can model the two-phase fluid side as flow within a tube or a set of tubes. The
two-phase fluid tubes use a boundary-following model to track the sub-cooled liquid (L),
vapor-liquid mixture (M), and super-heated vapor (V) in three zones. The relative amount
of space a zone occupies in the system is called a *zone length
fraction* within the system.

**Zone Length Fractions in the Two-Phase Fluid Piping**

The sum of the zone length fractions in the two-phase fluid tubing equals
`1`

. Port **Z** returns the zone
length fractions as a vector of physical signals for each of the three phases: [L, M,
V].

### Heat Exchanger Configuration

The heat exchanger effectiveness is based on the selected heat exchanger configuration, the fluid properties in each phase, the tube geometry and flow configuration on each side of the exchanger, and the usage and size of fins.

**Flow Arrangement**

The **Flow arrangement** parameter assigns the relative flow
paths between the two sides:

`Parallel flow`

indicates the fluids are moving in the same direction.`Counter flow`

indicates the fluids are moving in parallel, but opposite directions.`Cross flow`

indicates the fluids are moving perpendicular to each other.

**Thermal Mixing**

When **Flow arrangement** is set to ```
Cross
flow
```

, use the **Cross flow arrangement**
parameter to indicate whether the two-phase fluid or thermal liquid flows are
separated into multiple paths by baffles or walls. Without these separations,
the flow can mix freely and is considered *mixed*. Both
fluids, one fluid, or neither fluid can be mixed in the cross-flow arrangement.
Mixing homogenizes the fluid temperature along the direction of flow of the
second fluid, and varies perpendicular to the second fluid flow.

Unmixed flows vary in temperature both along and perpendicular to the flow path of the second fluid.

**Sample Cross-Flow Configurations**

Note that the flow direction during simulation does not impact the selected flow arrangement setting. The ports on the block do not reflect the physical positions of the ports in the physical heat exchange system.

All flow arrangements are single-pass, which means that the fluids do not make multiple turns in the exchanger for additional points of heat transfer. To model a multi-pass heat exchanger, you can arrange multiple Condenser Evaporator (TL-2P) blocks in series or in parallel.

For example, to achieve a two-pass configuration on the two-phase fluid side and a single-pass configuration on the thermal liquid side, you can connect the two-phase fluid sides in series and the thermal liquid sides to the same input in parallel (such as two Mass Flow Rate Source blocks with half of the total mass flow rate), as shown below.

**Flow Geometry**

The **Flow geometry** parameter sets the thermal liquid flow
arrangement as either inside a tube or set of tubes, or perpendicular to a tube
bank. You can also specify an empirical, generic configuration. The two-phase
fluid always flows inside a tube or set of tubes.

When **Flow geometry** is set to ```
Flow
perpendicular to bank of circular tubes
```

, use the
**Tube bank grid arrangement** parameter to define the
two-phase fluid tube bank alignment as either `Inline`

or `Staggered`

. The red, downward-pointing arrow
indicates the direction of thermal liquid flow. The Inline figure also shows the
**Number of tube rows along flow direction** and the
**Number of tube segments in each tube row** parameters.
Here, *flow direction* refers to the thermal liquid flow, and
*tube* refers to the two-phase fluid tubing. The
**Length of each tube segment in a tube row** parameter is
indicated in the Staggered figure.

**Fins**

The heat exchanger configuration does not have fins when the **Total fin surface
area** parameter is `0 m^2`

. Fins introduce
additional surface area for heat transfer. Each fluid side has a separate fin
area and parameters that describe the fins in that fluid. For example, when the
thermal liquid flows inside the tubes and the two-phase fluid flows outside of
the tubes, the **Total fin surface area** and **Fin
efficiency** parameters in the **Thermal Liquid
1** section describe the fins protruding into the tube. The
**Total fin surface area** and **Fin
efficiency** parameters in the **Two-Phase Fluid
2** section describe the fins outside of the tubes.

### Effectiveness-NTU Heat Transfer

The heat transfer rate is calculated for each fluid phase. In accordance with the three fluid zones that occur on the two-phase fluid side of the heat exchanger, the heat transfer rate is calculated in three sections.

The heat transfer in a zone is calculated as:

$${Q}_{zone}=\u03f5{C}_{\text{Min}}({T}_{\text{In,2P}}-{T}_{\text{In,TL}}),$$

where:

*C*_{Min}is the lesser of the heat capacity rates of the two fluids in that zone. The heat capacity rate is the product of the fluid specific heat,*c*_{p}, and the fluid mass flow rate.*C*_{Min}is always positive.*T*_{In,2P}is the zone inlet temperature of the two-phase fluid.*T*_{In,TL}is the zone inlet temperature of the thermal liquid.*ε*is the heat exchanger effectiveness.

Effectiveness is a function of the heat capacity rate and the number
of transfer units, *NTU*, and also varies based on the heat
exchanger flow arrangement, which is discussed in more detail in Effectiveness by Flow Arrangement. The
*NTU* is calculated as:

$$NTU=\frac{z}{{C}_{\text{Min}}R},$$

where:

*z*is the individual zone length fraction.*R*is the total thermal resistance between the two flows, due to convection, conduction, and any fouling on the tube walls:$$R=\frac{1}{{U}_{\text{2P}}{A}_{\text{Th,2P}}}+\frac{{F}_{\text{2P}}}{{A}_{\text{Th,2P}}}+{R}_{\text{W}}+\frac{{F}_{\text{TL}}}{{A}_{\text{Th,TL}}}+\frac{1}{{U}_{\text{TL}}{A}_{\text{Th,TL}}},$$

where:

*U*is the convective heat transfer coefficient of the respective fluid. This coefficient is discussed in more detail in Two-Phase Fluid Correlations and Thermal Liquid Correlations.*F*is the**Fouling factor**on the two-phase fluid or thermal liquid side, respectively.*R*_{W}is the**Thermal resistance through heat transfer surface**.*A*_{Th}is the heat transfer surface area of the respective side of the exchanger.*A*_{Th}is the sum of the wall surface area,*A*_{W}, and the**Total fin surface area**,*A*_{F}:$${A}_{\text{Th}}={A}_{\text{W}}+{\eta}_{\text{F}}{A}_{\text{F}},$$

where

*η*_{F}is the**Fin efficiency**.

The total heat transfer rate between the fluids is the sum of the heat transferred
in the three zones by the subcooled liquid
(*Q _{L}*), liquid-vapor mixture
(

*Q*), and superheated vapor (

_{M}*Q*):

_{V}$$Q={\displaystyle \sum {Q}_{\text{Z}}}={Q}_{\text{L}}+{Q}_{\text{M}}+{Q}_{\text{V}}.$$

**Effectiveness by Flow Arrangement**

The heat exchanger effectiveness varies according to its flow configuration and the mixing in each fluid. Below are the formulations for effectiveness calculated in the liquid and vapor zones for each configuration. The effectiveness is $$\epsilon =1-\mathrm{exp}(-NTU)$$ for all configurations in the mixture zone.

When

**Flow arrangement**is set to`Parallel flow`

:$$\u03f5=\frac{1-\text{exp}[-NTU(1+{C}_{\text{R}})]}{1+{C}_{\text{R}}}$$

When

**Flow arrangement**is set to`Counter flow`

:$$\u03f5=\frac{1-\text{exp}[-NTU(1-{C}_{\text{R}})]}{1-{C}_{\text{R}}\text{exp}[-NTU(1-{C}_{\text{R}})]}$$

When

**Flow arrangement**is set to`Cross flow`

and**Cross flow arrangement**is set to`Both fluids unmixed`

:$$\u03f5=1-\text{exp}\left\{\frac{NT{U}^{\text{0}\text{.22}}}{{C}_{\text{R}}}\left[\text{exp}\left(-{C}_{\text{R}}NT{U}^{\text{0}\text{.78}}\right)-1\right]\right\}$$

When

**Flow arrangement**is set to`Cross flow`

and**Cross flow arrangement**is set to`Both fluids mixed`

:$$\u03f5={\left[\frac{1}{1-\text{exp}\left(-NTU\right)}+\frac{{C}_{\text{R}}}{1-\text{exp}\left(-{C}_{\text{R}}NTU\right)}-\frac{1}{NTU}\right]}^{-1}$$

When one fluid is mixed and the other unmixed, the equation for
effectiveness depends on the relative heat capacity rates of the fluids.
When **Flow arrangement** is set to ```
Cross
flow
```

and **Cross flow arrangement**
is set to either ```
Thermal Liquid 1 mixed & Two-Phase
Fluid 2 unmixed
```

or ```
Thermal Liquid 1
unmixed & Two-Phase Fluid 2 mixed
```

:

When the fluid with C

_{max}is mixed and the fluid with C_{min}is unmixed:$$\u03f5=\frac{1}{{C}_{\text{R}}}\left(1-\text{exp}\left\{-{C}_{R}\left\{1-\mathrm{exp}\left(-NTU\right)\right\}\right\}\right)$$

When the fluid with C

_{min}is mixed and the fluid with C_{max}is unmixed:$$\u03f5=1-\text{exp}\left\{-\frac{1}{{C}_{\text{R}}}\left[1-\text{exp}\left(-{C}_{\text{R}}NTU\right)\right]\right\}$$

*C*_{R} denotes the ratio
between the heat capacity rates of the two fluids:

$${C}_{\text{R}}=\frac{{C}_{\text{Min}}}{{C}_{\text{Max}}}.$$

### Two-Phase Fluid Correlations

**Heat Transfer Coefficient**

The convective heat transfer coefficient varies according to the fluid Nusselt number:

$$U=\frac{\text{Nu}k}{{D}_{\text{H}}},$$

where:

*Nu*is the zone mean Nusselt number, which depends on the flow regime.*k*is the fluid phase thermal conductivity.*D*_{H}is tube hydraulic diameter.

For turbulent flows in the subcooled liquid or superheated vapor zones, the Nusselt number is calculated with the Gnielinski correlation:

$$\text{Nu}=\frac{\frac{{f}_{D}}{8}(\text{Re}-1000)\text{Pr}}{1+12.7\sqrt{\frac{f}{8}}({\text{Pr}}^{2/3}-1)},$$

where:

*Re*is the fluid Reynolds number.*Pr*is the fluid Prandtl number.

For turbulent flows in the liquid-vapor mixture zone, the Nusselt number is calculated with the Cavallini-Zecchin correlation:

$$\text{Nu}=\frac{{\text{aRe}}_{\text{SL}}^{b}{\text{Pr}}_{\text{SL}}^{c}\left\{{\left[\left(\sqrt{\frac{{\rho}_{\text{SL}}}{{\rho}_{\text{SV}}}}-1\right){x}_{\text{Out}}+1\right]}^{1+b}-{\left[\left(\sqrt{\frac{{\rho}_{\text{SL}}}{{\rho}_{\text{SV}}}}-1\right){x}_{\text{In}}+1\right]}^{1+b}\right\}}{\left(1+b\right)\left(\sqrt{\frac{{\rho}_{\text{SL}}}{{\rho}_{\text{SV}}}}-1\right)({x}_{\text{Out}}-{x}_{\text{In}})}.$$

where:

*Re*_{SL}is the Reynolds number of the saturated liquid.*Pr*_{SL}is the Prandtl number of the saturated liquid.*ρ*_{SL}is the density of the saturated liquid.*ρ*_{SV}is the density of the saturated vapor.*a*= 0.05,*b*= 0.8, and*c*= 0.33.

For laminar flows, the Nusselt number is set by the **Laminar flow
Nusselt number** parameter.

For transitional flows, the Nusselt number is a blend between the laminar and turbulent Nusselt numbers.

**Empirical Nusselt Number Formulation**

When the **Heat transfer coefficient model** parameter is set
to `Colburn equation`

, the Nusselt number for the
subcooled liquid and superheated vapor zones is calculated by the empirical the
Colburn equation:

$$\text{Nu}=a{\text{Re}}^{b}{\text{Pr}}^{c},$$

where *a*, *b*, and
*c* are defined in the **Coefficients [a, b, c] for
a*Re^b*Pr^c in liquid zone** and **Coefficients [a, b, c]
for a*Re^b*Pr^c in vapor zone** parameters.

The Nusselt number for liquid-vapor mixture zones is calculated with the
Cavallini-Zecchin equation, with the coefficients specified in the
**Coefficients [a, b, c] for a*Re^b*Pr^c in mixture zone**
parameter.

**Pressure Loss**

The pressure loss due to viscous friction varies depending on flow regime and
configuration. The pressure loss calculation uses the overall density, which is
the total fluid mass divided by the total fluid volume. When the
**Pressure loss model** parameter is
`Correlation for flow inside tubes`

, the pressure
loss due to friction depends on the Darcy friction factor.

For turbulent flows, when the Reynolds number is above the **Turbulent flow lower
Reynolds number limit** parameter, the block calculates the
pressure loss due to friction in terms of a calculated Darcy friction factor.
The pressure differential between port **A1** and the internal
node I1 is:

$${p}_{\text{A1}}-{p}_{\text{I1}}=\frac{{f}_{\text{D,A}}{\dot{m}}_{\text{A1}}\left|{\dot{m}}_{\text{A1}}\right|}{2\rho {D}_{\text{H}}{A}_{\text{CS}}^{2}}\left(\frac{L+{L}_{\text{Add}}}{2}\right),$$

where:

$$\dot{m}$$

_{A1}is the total flow rate through port**A1**.*f*is the Darcy friction factor according to the Haaland correlation. When the_{D,A}**Local resistance specification**parameter is`Aggregate equivalent length`

,$${f}_{\text{D,A1}}={\left\{-1.8{\text{log}}_{\text{10}}\left[\frac{6.9}{{\text{Re}}_{\text{A1}}}+{\left(\frac{{\u03f5}_{\text{R}}}{3.7{D}_{\text{H}}}\right)}^{1.11}\right]\right\}}^{\text{-2}},$$

where

*ε*_{R}is the value of the**Internal surface absolute roughness**parameter. The friction factor is dependent on the Reynolds number, and the block calculates this value at both ports for each liquid.*L*is the value of the**Total length of each tube**parameter.*L*_{Add}is the value of the**Aggregate equivalent length of local resistances**parameter, which is the equivalent length of a tube that introduces the same amount of loss as the sum of the losses due to other local resistances in the tube.*A*is the tube cross-sectional area._{CS}

The pressure differential between port **B1**
and internal node I1 is:

$${p}_{\text{B1}}-{p}_{\text{I1}}=\frac{{f}_{\text{D,B}}{\dot{m}}_{\text{B1}}\left|{\dot{m}}_{\text{B1}}\right|}{2\rho {D}_{\text{H}}{A}_{\text{CS}}^{2}}\left(\frac{L+{L}_{\text{Add}}}{2}\right),$$

where $$\dot{m}$$_{B1} is the total flow rate through port
**B1**.

When the **Local resistance specification** parameter is
`Aggregate equivalent length`

, the Darcy friction
factor at port **B1** is:

$${f}_{\text{D,B1}}={\left\{-1.8{\text{log}}_{\text{10}}\left[\frac{6.9}{{\text{Re}}_{\text{B1}}}+{\left(\frac{{\u03f5}_{\text{R}}}{3.7{D}_{\text{H}}}\right)}^{1.11}\right]\right\}}^{\text{-2}}.$$

When the **Local resistance specification** parameter is
`Local loss coefficient`

, the Darcy friction
factors at ports **A1** and **B1** are

$$\begin{array}{l}{f}_{\text{D,A1}}={\left\{-1.8{\text{log}}_{\text{10}}\left[\frac{6.9}{{\text{Re}}_{A1}}+{\left(\frac{{\u03f5}_{\text{R}}}{3.7{D}_{\text{H}}}\right)}^{1.11}\right]\right\}}^{\text{-2}}+{C}_{localloss}\left(\frac{{D}_{H}}{L}\right)\\ {f}_{\text{D,B1}}={\left\{-1.8{\text{log}}_{\text{10}}\left[\frac{6.9}{{\text{Re}}_{B1}}+{\left(\frac{{\u03f5}_{\text{R}}}{3.7{D}_{\text{H}}}\right)}^{1.11}\right]\right\}}^{\text{-2}}+{C}_{localloss}\left(\frac{{D}_{H}}{L}\right)\end{array}$$

where *C _{localloss}*
is the value of the

**Total local loss coefficient**parameter.

For laminar flows, when the Reynolds number is below the **Laminar flow upper
Reynolds number limit** parameter, the block calculates the
pressure loss due to friction in terms of the **Laminar friction
constant for Darcy friction factor** parameter,
*λ*. *λ* is a user-defined parameter when
**Tube cross-section** is
`Generic`

. Otherwise, the block calculates the
value internally. The pressure differential between port **A1**
and internal node I1 is:

$${p}_{\text{A1}}-{p}_{\text{I1}}=\frac{\lambda \mu {\dot{m}}_{\text{A1}}}{2\rho {D}_{\text{H}}^{2}{A}_{CS}}\left(\frac{L+{L}_{\text{Add}}}{2}\right),$$

where *μ* is the fluid dynamic viscosity.
The pressure differential between port **B1** and internal node
I1 is:

$${p}_{\text{B1}}-{p}_{\text{I1}}=\frac{\lambda \mu {\dot{m}}_{\text{B1}}}{2\rho {D}_{\text{H}}^{2}{A}_{CS}}\left(\frac{L+{L}_{\text{Add}}}{2}\right).$$

For transitional flows, the pressure differential due to viscous friction is a smoothed blend between the values for laminar and turbulent pressure losses.

**Empirical Pressure Loss Formulation**

When **Pressure loss model** is set to ```
Pressure
loss coefficient
```

, the pressure losses due to viscous friction
are calculated with an empirical pressure loss coefficient,
*ξ*.

The pressure differential between port **A2** and internal
node I2 is:

$${p}_{\text{A2}}-{p}_{\text{I2}}=\frac{1}{2}\xi \frac{{\dot{m}}_{\text{A2}}\left|{\dot{m}}_{\text{A2}}\right|}{2\rho {A}_{\text{CS}}^{2}}.$$

The pressure differential between port
**B2** and internal node I2 is:

$${p}_{\text{B2}}-{p}_{\text{I2}}=\frac{1}{2}\xi \frac{{\dot{m}}_{\text{B2}}\left|{\dot{m}}_{\text{B2}}\right|}{2\rho {A}_{\text{CS}}^{2}}.$$

### Thermal Liquid Correlations

**Heat Transfer Coefficient for Flows Inside One or More Tubes**

When the thermal liquid **Flow geometry** is set to
`Flow inside one or more tubes`

, the Nusselt number
is calculated according to the Gnielinski correlation in the same manner as
two-phase subcooled liquid or superheated vapor. See Heat Transfer Coefficient for more
information.

**Heat Transfer Coefficient for Flows Across a Tube Bank**

When the thermal liquid **Flow geometry** is set to
`Flow perpendicular to bank of circular tubes`

, the
Nusselt number is calculated based on the Hagen number, Hg, and depends on the
**Tube bank grid arrangement** setting:

$$\text{Nu}=\{\begin{array}{cc}0.404L{q}^{\text{1/3}}{\left(\frac{\text{Re}+1}{\text{Re}+1000}\right)}^{0.1},& Inline\\ 0.404L{q}^{1/3},& Staggered\end{array}$$

where:

$$Lq=\{\begin{array}{cc}1.18\text{Pr}\left(\frac{4{l}_{\text{T}}/\pi -D}{{l}_{\text{L}}}\right)\text{Hg}(\text{Re}),& Inline\\ 0.92\text{Pr}\left(\frac{4{l}_{\text{T}}/\pi -D}{{l}_{\text{D}}}\right)\text{Hg}(\text{Re}),& Staggeredwith{l}_{L}\ge D\\ 0.92\text{Pr}\left(\frac{4{l}_{\text{T}}{l}_{\text{L}}/\pi -{D}^{2}}{{l}_{\text{L}}{l}_{\text{D}}}\right)\text{Hg}(\text{Re}),& Staggeredwith{l}_{L}<D\end{array}$$

*D*is the**Tube outer diameter**.*l*_{L}is the**Longitudinal tube pitch (along flow direction)**, the distance between the tube centers along the flow direction.*Flow direction*refers to the thermal liquid flow.*l*_{T}is the**Transverse tube pitch (perpendicular to flow direction)**, shown in the figure below. The transverse pitch is the distance between the centers of the two-phase fluid tubing in one row.*l*_{D}is the diagonal tube spacing, calculated as $${l}_{\text{D}}=\sqrt{{\left(\frac{{l}_{\text{T}}}{2}\right)}^{2}+{l}_{\text{L}}^{2}}.$$

For more information on calculating the Hagen number, see [3].

The longitudinal and transverse pitch distances are the same for both grid bank arrangement types.

**Cross-Section of Two-Phase Fluid Tubing with Pitch Measurements**

**Empirical Nusselt Number Formulation**

When the **Heat transfer coefficient model** is set to
`Colburn equation`

or when **Flow
geometry** is set to `Generic`

, the
Nusselt number is calculated by the empirical the Colburn equation:

$$\text{Nu}=a{\text{Re}}^{b}{\text{Pr}}^{c},$$

where *a*, *b*, and
*c* are the values defined in the** Coefficients
[a, b, c] for a*Re^b*Pr^c** parameter.

**Pressure Loss for Flow Inside Tubes**

When the thermal liquid **Flow geometry** parameter is ```
Flow
inside one or more tubes
```

, the pressure loss is calculated the
same way as for two-phase flows, with the respective Darcy friction factor,
density, mass flow rates, and pipe lengths of the thermal liquid side. See Pressure Loss for more
information.

**Pressure Loss for Flow Across Tube Banks**

When the thermal liquid **Flow geometry** is set to
`Flow perpendicular to bank of circular tubes`

, the
Hagen number is used to calculate the pressure loss due to viscous friction. The
pressure differential between port **A1** and internal node I1 is:

$${p}_{\text{A1}}-{p}_{\text{I1}}=\frac{1}{2}\frac{{\mu}^{2}{N}_{\text{R}}}{\rho {D}^{2}}\text{Hg}(\text{Re}),$$

where:

*μ*_{TL}is the fluid dynamic viscosity.*N*_{R}is the**Number of tube rows along flow direction**. This is the number of two-phase fluid tube rows along the thermal liquid flow direction.

The pressure differential between port **B1**
and internal node I1 is:

$${p}_{\text{B1}}-{p}_{\text{I1}}=\frac{1}{2}\frac{{\mu}^{2}{N}_{\text{R}}}{\rho {D}^{2}}\text{Hg}(\text{Re}).$$

**Empirical Pressure Loss Formulation**

When the **Pressure loss model** parameter is ```
Euler number
per tube row
```

or when the **Flow geometry**
parameter is `Generic`

, the pressure loss due to
viscous friction is calculated with a pressure loss coefficient, in terms of the
Euler number, *Eu*:

$$\text{Eu}=\frac{\xi}{{N}_{R}},$$

where *ξ* is the empirical pressure loss
coefficient.

The pressure differential between port **A1** and internal
node I1 is:

$${p}_{\text{A1}}-{p}_{\text{I1}}=\frac{1}{2}{N}_{R}Eu\frac{{\dot{m}}_{\text{A1}}\left|{\dot{m}}_{\text{A1}}\right|}{2\rho {A}_{\text{CS}}^{2}}.$$

The pressure differential between port
**B1** and internal node I1 is:

$${p}_{\text{B1}}-{p}_{\text{I1}}=\frac{1}{2}{N}_{R}Eu\frac{{\dot{m}}_{\text{B1}}\left|{\dot{m}}_{\text{B1}}\right|}{2\rho {A}_{\text{CS}}^{2}}.$$

### Conservation Equations

**Two-Phase Fluid**

The total mass accumulation rate in the two-phase fluid is defined as:

$$\frac{d{M}_{\text{2P}}}{dt}={\dot{m}}_{\text{A2}}+{\dot{m}}_{\text{B2}},$$

where:

*M*is the total mass of the two-phase fluid._{2P}$$\dot{m}$$

_{A2}is the mass flow rate of the fluid at port**A2**.$$\dot{m}$$

_{B2}is the mass flow rate of the fluid at port**B2**.

The flow is positive when flowing into the block through the port.

The energy conservation equation relates the change in specific internal energy to the heat transfer by the fluid:

$${M}_{2P}\frac{d{u}_{2P}}{dt}+{u}_{2P}\left({\dot{m}}_{A2}+{\dot{m}}_{B2}\right)={\varphi}_{\text{A2}}+{\varphi}_{\text{B2}}-Q,$$

where:

*u*_{2P}is the two-phase fluid specific internal energy.*φ*_{A2}is the energy flow rate at port**A2**.*φ*_{B2}is the energy flow rate at port**B2**.*Q*is heat transfer rate, which is positive when leaving the two-phase fluid volume.

**Thermal Liquid**

The total mass accumulation rate in the thermal liquid is defined as:

$$\frac{d{M}_{\text{TL}}}{dt}={\dot{m}}_{\text{A1}}+{\dot{m}}_{\text{B1}}.$$

The energy conservation equation is:

$${M}_{TL}\frac{d{u}_{TL}}{dt}+{u}_{TL}\left({\dot{m}}_{A1}+{\dot{m}}_{B1}\right)={\varphi}_{\text{A1}}+{\varphi}_{\text{B1}}+Q,$$

where:

*ϕ*_{A1}is the energy flow rate at port**A1**.*ϕ*_{B1}is the energy flow rate at port**B1**.

The heat transferred to or from the thermal liquid,
*Q*, is equal to the heat transferred from or to the
two-phase fluid.

## Ports

### Conserving

### Output

## Parameters

## References

[1] *2013
ASHRAE Handbook - Fundamentals.* American Society of Heating,
Refrigerating and Air-Conditioning Engineers, Inc., 2013.

[2] Çengel, Yunus A. *Heat and Mass Transfer: A Practical Approach*. 3rd ed,
McGraw-Hill, 2007.

[3] Shah, R. K., and Dušan P.
Sekulić. *Fundamentals of Heat Exchanger Design*. John
Wiley & Sons, 2003.

[4] White, Frank M. *Fluid Mechanics*. 6th ed, McGraw-Hill, 2009.

## Extended Capabilities

## Version History

**Introduced in R2020b**
