# plot3m

Project 3-D lines and points on map axes

## Syntax

```h = plot3m(lat,lon,z) h = plot3m(lat,lon,LineSpec) h = plot3m(lat,lon,PropertyName,PropertyValue,...) ```

## Description

`h = plot3m(lat,lon,z)` displays projected line objects on the current map axes. `lat` and `lon` are the latitude and longitude coordinates, respectively, of the line object to be projected. Note that this ordering is conceptually reversed from the MATLAB® `line` function, because the vertical (y) coordinate comes first. However, the ordering latitude, then longitude, is standard geographic usage. `lat` and `lon` must be the same size, and in the `AngleUnits` of the map axes. `z` is the altitude data associated with each point in `lat` and `lon`. The object handle for the displayed line can be returned in `h`.

The units of `z` are arbitrary, except when using the globe projection. In the case of `globe`, `z` should have the same units as the radius of the earth or semimajor axis specified in the `'geoid'` (reference ellipsoid) property of the map axes. This implies that when the reference ellipsoid is a unit sphere, the units of `z` are earth radii.

`h = plot3m(lat,lon,LineSpec)` specifies the line style, marker, and color.

`h = plot3m(lat,lon,PropertyName,PropertyValue,...)` allows the specification of any number of property name/property value pairs for any properties recognized by the MATLAB `line` function except for `XData`, `YData`, and `ZData`.

## Examples

```axesm sinusoid; framem; view(3) [lats,longs] = interpm([45 -45 -45 45 45 -45]',... [-100 -100 100 100 -100 -100]',1); z = (1:671)'/100; plot3m(lats,longs,z,'m')```

collapse all

### Line Style, Marker, and Color

Specify the line style, marker, and color as a character vector or string containing symbols. The symbols can appear in any order. You do not need to specify all three characteristics (line style, marker, and color). For example, specify a red dashed line using `'--r'`.

Line StyleDescriptionResulting Line
`'-'`Solid line

`'--'`Dashed line

`':'`Dotted line

`'-.'`Dash-dotted line

MarkerDescriptionResulting Marker
`'o'`Circle

`'+'`Plus sign

`'*'`Asterisk

`'.'`Point

`'x'`Cross

`'_'`Horizontal line

`'|'`Vertical line

`'s'`Square

`'d'`Diamond

`'^'`Upward-pointing triangle

`'v'`Downward-pointing triangle

`'>'`Right-pointing triangle

`'<'`Left-pointing triangle

`'p'`Pentagram

`'h'`Hexagram

Color NameShort NameRGB TripletAppearance
`'red'``'r'``[1 0 0]`

`'green'``'g'``[0 1 0]`

`'blue'``'b'``[0 0 1]`

`'cyan'` `'c'``[0 1 1]`

`'magenta'``'m'``[1 0 1]`

`'yellow'``'y'``[1 1 0]`

`'black'``'k'``[0 0 0]`

`'white'``'w'``[1 1 1]`

## Tips

`plot3m` is the mapping equivalent of the MATLAB `plot3` function.
