# optimvalues

Create values for optimization problem

## Syntax

``val = optimvalues(prob,dataname1,dataval1,...)``

## Description

example

````val = optimvalues(prob,dataname1,dataval1,...)` creates an `OptimizationValues` object for the problem `prob`. Specify all variable names and their associated values, and optionally objective or constraint values, by using name-value arguments. For example, to specify that `x` takes odd values from 1 through 99, val = optimvalues(prob,x=1:2:99); Use `val` as an initial point or initial population for `prob`.```

## Examples

collapse all

To create initial points for `ga` (genetic algorithm solver) in the problem-based approach, create an `OptimizationValues` object using `optimvalues`.

Create optimization variables for a 2-D problem with Rosenbrock's function as the fitness (objective) function.

```x = optimvar("x",LowerBound=-5,UpperBound=5); y = optimvar("y",LowerBound=-5,UpperBound=5); rosenbrock = (10*(y - x.^2)).^2 + (1-x).^2; prob = optimproblem(Objective=rosenbrock);```

Create 100 random 2-D points within the bounds. The points must be row vectors.

```rng default % For reproducibility xval = -5 + 10*rand(1,100); yval = -5 + 10*rand(1,100);```

Create the initial point values object. Because you do not calculate the fitness values, the values appear as `NaN` in the display.

`vals = optimvalues(prob,x=xval,y=yval)`
```vals = 1x100 OptimizationValues vector with properties: Variables properties: x: [3.1472 4.0579 -3.7301 4.1338 1.3236 -4.0246 -2.2150 ... ] y: [-3.3782 2.9428 -1.8878 0.2853 -3.3435 1.0198 -2.3703 ... ] Objective properties: Objective: [NaN NaN NaN NaN NaN NaN NaN NaN NaN NaN NaN NaN NaN NaN ... ] ```

Solve the problem using `ga` starting from the initial point `vals`. Set `ga` options to have a population of 100.

```opts = optimoptions("ga",PopulationSize=100); [sol,fv] = solve(prob,vals,Solver="ga",Options=opts)```
```Solving problem using ga. Optimization terminated: average change in the fitness value less than options.FunctionTolerance. ```
```sol = struct with fields: x: 1.0000 y: 1.0000 ```
```fv = 4.1061e-09 ```

`ga` returns a solution very near the true solution `x = 1, y = 1` with a fitness value near `0`.

To create initial points for `surrogateopt` in the problem-based approach, create an `OptimizationValues` object using `optimvalues`.

Create optimization variables for a 2-D problem with Rosenbrock's function as the objective function.

```x = optimvar("x",LowerBound=-5,UpperBound=5); y = optimvar("y",LowerBound=-5,UpperBound=5); rosenbrock = (10*(y - x.^2)).^2 + (1 - x).^2; prob = optimproblem(Objective=rosenbrock);```

Create constraints that the solution is in a disc of radius 2 about the origin and lies below the line y = 1 + x.

```disc = x^2 + y^2 <= 2^2; prob.Constraints.disc = disc; line = y <= 1 + x; prob.Constraints.line = line;```

Create 40 random 2-D points within the bounds. The points must be row vectors.

```rng default % For reproducibility N = 40; xval = -5 + 10*rand(1,N); yval = -5 + 10*rand(1,N);```

Evaluate Rosenbrock's function on the random points. The function values must be a row vector. This step is optional. If you do not provide the function values, `surrogateopt` evaluates the objective function at the points `(xval,yval)`. When you have the function values, you can save time for the solver by providing the values as data.

```fval = zeros(1,N); for i = 1:N p0 = struct('x',xval(i),'y',yval(i)); fval(i) = evaluate(rosenbrock,p0); end```

Evaluate the constraints on the points. The constraint values must be row vectors. This step is optional. If you do not provide the constraint values, `surrogateopt` evaluates the constraint functions at the points `(xval,yval)`.

```discval = zeros(1,N); lineval = zeros(1,N); for i = 1:N p0 = struct('x',xval(i),'y',yval(i)); discval(i) = infeasibility(disc,p0); lineval(i) = infeasibility(line,p0); end```

Create the initial point values object.

`vals = optimvalues(prob,x=xval,y=yval,Objective=fval,disc=discval,line=lineval)`
```vals = 1x40 OptimizationValues vector with properties: Variables properties: x: [3.1472 4.0579 -3.7301 4.1338 1.3236 -4.0246 -2.2150 ... ] y: [-0.6126 -1.1844 2.6552 2.9520 -3.1313 -0.1024 -0.5441 ... ] Objective properties: Objective: [1.1067e+04 3.1166e+04 1.2698e+04 1.9992e+04 2.3846e+03 ... ] Constraints properties: disc: [6.2803 13.8695 16.9638 21.8023 7.5568 12.2078 1.2024 0 ... ] line: [0 0 5.3853 0 0 2.9222 0.6709 0 0 0 0.1841 0 0 0 0 2.5648 ... ] ```

Solve the problem using `surrogateopt` starting from the initial point `vals`.

`[sol,fv] = solve(prob,vals,Solver="surrogateopt")`
```Solving problem using surrogateopt. ``` ```surrogateopt stopped because it exceeded the function evaluation limit set by 'options.MaxFunctionEvaluations'. ```
```sol = struct with fields: x: 0.7961 y: 0.6340 ```
```fv = 0.0416 ```

`surrogateopt` returns a solution somewhat near the true solution `x = 1, y = 1` with an objective function value near `0`.

## Input Arguments

collapse all

Optimization problem, specified as an `OptimizationProblem` object. Create `prob` using `optimproblem`.

To obtain useful output from `optimvalues`, you must also include some data in name-value arguments.

### Name-Value Arguments

Specify optional pairs of arguments as `Name1=Value1,...,NameN=ValueN`, where `Name` is the argument name and `Value` is the corresponding value. Name-value arguments must appear after other arguments, but the order of the pairs does not matter.

Example: `val = optimvalues(x=xvals,y=yvals)`

Data for a variable, named objective, or named constraint, specified as a real double array. Specify all data names for the variables. The objective and constraint function names are optional.

When you specify `nval` points, the values for each `dataname` argument must have the following dimensions.

`prob.property.name``size(value)`
Scalar or vector`numel(prob.property.name)`-by-`nval`
Matrix or array`size(prob.property.name)`-by-`nval`

In particular, if `dataname` is a vector, the value of the `dataname` argument is a matrix with `nval` columns. For example, if the `'x'` variable is a row vector of length 2, and `nval` is 3, then the `'x'` variable specification might be:

`val = optimvalues(prob,'x',[1 2 3; 4 5 -6]);`

This specification means that `'x'` takes the three values `[1,4]`, `[2,5]`, and `[3,-6]`.

Example: For scalar `'x'` and two-element row vector `'y'` with `nval = 2`: ```val = optimvalues(prob,x=[5,3],y=[1 2;3 4])```. The output `val` has two values: `x = 5, y = [1 3]` and ```x = 3, y = [2 4]```.

Data Types: `double`

Values for an unnamed objective function, specified as a real double array. The size of the values is the same as in `dataname`.

You can specify values of multiple objective functions for optimization problems in two ways:

• The `Objective` property of the optimization problem is a function handle, where the function returns a vector or array. In this case, specify the value as a matrix. Each matrix row represents the values of one objective at the various points. Each column represents the values of the various objectives at one point.

• The `Objective` property of the optimization problem has multiple named objectives. In this case, specify the values for each named objective using its name as a `dataname` argument.

These solvers use any supplied objective function values:

• `ga`

• `gamultiobj`

• `paretosearch`

• `surrogateopt`

Example: For one objective and two points, ```val = optimvalues(prob,x=[3,5],Objective=[exp(3)+1,exp(5)-1])```

Data Types: `double`

Values for an unnamed constraint function, specified as a real double array. The size of the values is the same as in `dataname`.

You can specify values of multiple constraint functions for optimization problems in two ways:

• The `Constraints` property of the optimization problem is a function handle, where the function returns an array. In this case, specify the values as an array with one more dimension than the function returns.

• The `'Constraints'` property of the optimization problem has multiple named constraints. In this case, specify the values for each named objective using its name as a `dataname` argument.

These solvers use any supplied nonlinear constraint function values:

• `paretosearch`

• `surrogateopt`

These solvers ensure that linear constraints are satisfied at all iterations or for all population members:

• `ga`

• `gamultiobj`

• `paretosearch`

• `patternsearch`

• `surrogateopt`

Example: For two points and three constraints, ```val = optimvalues(prob,x=[3,5],Objective=[exp(3)+1,exp(5)-1],Constraints=[4 5;-7 -2;0.2 12])```

Data Types: `double`

## Output Arguments

collapse all

Point and function values, returned as a vector of `OptimizationValues` objects. The vector has `nval` entries, where `nval` is the number of points in `val`.

## Version History

Introduced in R2022a
