Power Electronics Templates for Simulink Real-Time
This package contains models of power electronics components for hardware-in-the-loop testing with Simulink® Real-Time™. The templates are generated with HDL Coder™ and are ready to run on the Speedgoat IO334 FPGA I/O module with IO334-21 plug-in.
The following templates are included:
- Permanent magnet synchronous motor (PMSM) with 2-level inverter
- Permanent magnet synchronous motor (PMSM) with NPC inverter
- Induction motor with 2-level inverter
The templates are designed to be customizable and extendable, HDL Coder is required for design customizations:
- All HDL compatible source blocks used to synthesize bitstream files are included for reference, which can be found in the lib directory;
- Scripts for setting up "HDL workflow advisor" are included for each template.
- Open the project file slrt_power_electronics_templates.prj
- Explore templates directory for the desired template
To learn how to use power electronics template to do permanent magnet synchronous machine field-oriented control and use App Designer application to control simulation, see Examples.
Requires MATLAB® release R2022b or newer
For design customizations, the following products are also required:
Before proceeding, ensure that the below products are installed:
- Speedgoat I/O Blockset
- Speedgoat HDL Coder Integration Packages
Copyright 2022 The MathWorks, Inc.
