RF Filter Design

Design RF filters such as Butterworth, Chebyshev, Inverse Chebyshev

Use the RF Toolbox™ rffilter object to design Butterworth, Chebyshev or Inverse Chebyshev filters with highpass, lowpass, bandpass, and bandstop responses.

You can also use the rffilter object or RFCKT filters to design filters with different implementation types.


expand all

rffilterCreate Butterworth, Chebyshev, and inverse Chebyshev RF filter
rfckt.lcbandpasspiBandpass pi filter
rfckt.lcbandpassteeBandpass tee filter
rfckt.lcbandstoppiBandstop pi filter
rfckt.lcbandstopteeBandstop tee filter
rfckt.lchighpasspiHighpass pi filter
rfckt.lchighpassteeHighpass tee filter
rfckt.lclowpasspiLowpass pi filter
rfckt.lclowpassteeLowpass tee filter
