Prepare Model Inputs and Outputs

Define external interfaces for input data and control signals, define output signals for viewing and recording simulation results

You can load signal data that you create in MATLAB® or a spreadsheet or that you save during simulation. The kind of signal data you want to load impacts your choice of signal loading techniques.

For an overview of how to use MATLAB data in Simulink® models, save simulation data, and log signals for analysis, watch Loading and Logging Data (4 min, 9 sec) and see Provide Signal Data for Simulation.
