Extend Architectural Elements

Add custom properties to architectural elements using stereotypes

System Composer™ provides built-in element types: components, ports, and connectors. Create element stereotypes (2) to extend element types with additional properties that help capture and analyze non-functional requirements. Package stereotypes into profiles (1) to provide self-consistent architectural domains. Share profiles between models to ensure consistency within a project.

Each built-in element has a tag (7). Tags (7) have a name and an optional description. Stereotypes (2) have names and also a set of additional properties that can be used to capture additional data about an element. Model elements can have multiple stereotypes.

Functions

`createProfile`	Create profile
`loadProfile`	Load profile
`applyProfile`	Apply profile to a model
`removeProfile`	Remove profile from a model
`addStereotype`	Add a stereotype to the profile
`applyStereotype`	Apply a stereotype to a model element
`applyStereotypeToAllComponents`	Apply stereotype to all components in the specified architecture
`applyStereotypeToAllConnections`	Apply stereotype to all components in the specified architecture
`applyStereotypeToAllPorts`	Apply stereotype to all ports in the specified architecture
`removeStereotype`	Remove a stereotype from a model element
`addProperty`	Add a property to a stereotype
`getProperty`	Get the property value corresponding to a stereotype applied to the element
`setProperty`	Set the property value corresponding to a stereotype applied to the element
`removeProperty`	Remove a property from a stereotype
`destroy`	Remove and destroy a model element

Topics

Define Profiles and Stereotypes

Define specialized model element types based on components, ports, and connectors.

Use Stereotypes and Profiles

Import profiles, apply stereotypes to model elements, and extend existing stereotypes.

Analyze Architecture

Write analyses based on element properties to perform data-driven trade studies and verify system requirements.
