Linear Regression

Introduction

A data model explicitly describes a relationship between predictor and response variables. Linear regression fits a data model that is linear in the model coefficients. The most common type of linear regression is a least-squares fit, which can fit both lines and polynomials, among other linear models.

Before you model the relationship between pairs of quantities, it is a good idea to perform correlation analysis to establish if a linear relationship exists between these quantities. Be aware that variables can have nonlinear relationships, which correlation analysis cannot detect. For more information, see Linear Correlation.

The MATLAB^® Basic Fitting UI helps you to fit your data, so you can calculate model coefficients and plot the model on top of the data. For an example, see Example: Using Basic Fitting UI. You also can use the MATLAB polyfit and polyval functions to fit your data to a model that is linear in the coefficients. For an example, see Programmatic Fitting.

If you need to fit data with a nonlinear model, transform the variables to make the relationship linear. Alternatively, try to fit a nonlinear function directly using either the Statistics and Machine Learning Toolbox™ nlinfit function, the Optimization Toolbox™ lsqcurvefit function, or by applying functions in the Curve Fitting Toolbox™.

This topic explains how to:

• Perform simple linear regression using the \ operator.

• Use correlation analysis to determine whether two quantities are related to justify fitting the data.

• Fit a linear model to the data.

• Evaluate the goodness of fit by plotting residuals and looking for patterns.

• Calculate measures of goodness of fit R² and adjusted R²

Simple Linear Regression

This example shows how to perform simple linear regression using the accidents dataset. The example also shows you how to calculate the coefficient of determination $$R^2$$ to evaluate the regressions. The accidents dataset contains data for fatal traffic accidents in US states.

Linear regression models the relation between a dependent, or response, variable $$y$$ and one or more independent, or predictor, variables $$x_1,...,x_n$$. Simple linear regression considers only one independent variable using the relation

$$y={\beta }_0+{\beta }_{1}x+ϵ,$$

where $${\beta }_0$$ is the y-intercept, $${\beta }_1$$ is the slope (or regression coefficient), and $$ϵ$$ is the error term.

Start with a set of $$n$$ observed values of $$x$$ and $$y$$ given by $$(x_1,y_1)$$, $$(x_2,y_2)$$, ..., $$(x_n,y_n)$$. Using the simple linear regression relation, these values form a system of linear equations. Represent these equations in matrix form as

$$\left[\begin{array}{c}{y}_1\\ y_2\\ ⋮\\ y_n\end{array}\right]=\left[\begin{array}{cc}1& x_1\\ 1& x_2\\ ⋮& ⋮\\ 1& x_n\end{array}\right]\left[\begin{array}{c}{\beta }_0\\ {\beta }_1\end{array}\right].$$

Let

$$Y=\left[\begin{array}{c}{y}_1\\ y_2\\ ⋮\\ y_n\end{array}\right],X=\left[\begin{array}{cc}1& x_1\\ 1& x_2\\ ⋮& ⋮\\ 1& x_n\end{array}\right],B=\left[\begin{array}{c}{\beta }_0\\ {\beta }_1\end{array}\right].$$

The relation is now $$Y=XB$$.

In MATLAB, you can find $$B$$ using the mldivide operator as B = X\Y.

From the dataset accidents, load accident data in y and state population data in x. Find the linear regression relation $$y={\beta }_{1}x$$ between the accidents in a state and the population of a state using the \ operator. The \ operator performs a least-squares regression.

load accidents
x = hwydata(:,14); %Population of states
y = hwydata(:,4); %Accidents per state
format long
b1 = x\y

b1 =
     1.372716735564871e-04

b1 is the slope or regression coefficient. The linear relation is $$y={\beta }_{1}x=0.0001372x$$.

Calculate the accidents per state yCalc from x using the relation. Visualize the regression by plotting the actual values y and the calculated values yCalc.

yCalc1 = b1*x;
scatter(x,y)
hold on
plot(x,yCalc1)
xlabel('Population of state')
ylabel('Fatal traffic accidents per state')
title('Linear Regression Relation Between Accidents & Population')
grid on

Improve the fit by including a y-intercept $${\beta }_0$$ in your model as $$y={\beta }_0+{\beta }_{1}x$$. Calculate $${\beta }_0$$ by padding x with a column of ones and using the \ operator.

X = [ones(length(x),1) x];
b = X\y

b = 2×1
102 ×

   1.427120171726538
   0.000001256394274

This result represents the relation $$y={\beta }_0+{\beta }_{1}x=142.7120+0.0001256x$$.

Visualize the relation by plotting it on the same figure.

yCalc2 = X*b;
plot(x,yCalc2,'--')
legend('Data','Slope','Slope & Intercept','Location','best');

From the figure, the two fits look similar. One method to find the better fit is to calculate the coefficient of determination, $$R^2$$. $$R^2$$ is one measure of how well a model can predict the data, and falls between $$0$$ and $$1$$. The higher the value of $$R^2$$, the better the model is at predicting the data.

Where $$\underset{}{\overset{ˆ}{y}}$$ represents the calculated values of $$y$$ and $$\underset{}{\overset{‾}{y}}$$ is the mean of $$y$$, $$R^2$$ is defined as

$$R^2=1-\frac{\sum _{i=1}^n{(y_i-{\underset{}{\overset{ˆ}{y}}}_i)}^2}{\sum _{i=1}^n{(y_i-\underset{}{\overset{‾}{y}})}^2}.$$

Find the better fit of the two fits by comparing values of $$R^2$$. As the $$R^2$$ values show, the second fit that includes a y-intercept is better.

Rsq1 = 1 - sum((y - yCalc1).^2)/sum((y - mean(y)).^2)

Rsq1 =
   0.822235650485566

Rsq2 = 1 - sum((y - yCalc2).^2)/sum((y - mean(y)).^2)

Rsq2 =
   0.838210531103428

Residuals and Goodness of Fit

Residuals are the difference between the observed values of the response (dependent) variable and the values that a model predicts. When you fit a model that is appropriate for your data, the residuals approximate independent random errors. That is, the distribution of residuals ought not to exhibit a discernible pattern.

Producing a fit using a linear model requires minimizing the sum of the squares of the residuals. This minimization yields what is called a least-squares fit. You can gain insight into the “goodness” of a fit by visually examining a plot of the residuals. If the residual plot has a pattern (that is, residual data points do not appear to have a random scatter), the randomness indicates that the model does not properly fit the data.

Evaluate each fit you make in the context of your data. For example, if your goal of fitting the data is to extract coefficients that have physical meaning, then it is important that your model reflect the physics of the data. Understanding what your data represents, how it was measured, and how it is modeled is important when evaluating the goodness of fit.

One measure of goodness of fit is the coefficient of determination, or R² (pronounced r-square). This statistic indicates how closely values you obtain from fitting a model match the dependent variable the model is intended to predict. Statisticians often define R² using the residual variance from a fitted model:

R² = 1 – SS_resid / SS_total

SS_resid is the sum of the squared residuals from the regression. SS_total is the sum of the squared differences from the mean of the dependent variable (total sum of squares). Both are positive scalars.

To learn how to compute R² when you use the Basic Fitting tool, see R2, the Coefficient of Determination. To learn more about calculating the R² statistic and its multivariate generalization, continue reading here.

Example: Computing R² from Polynomial Fits

You can derive R² from the coefficients of a polynomial regression to determine how much variance in y a linear model explains, as the following example describes:

1. Create two variables, x and y, from the first two columns of the count variable in the data file count.dat:

   load count.dat
   x = count(:,1);
   y = count(:,2);

2. Use polyfit to compute a linear regression that predicts y from x:

   p = polyfit(x,y,1)

   p =
       1.5229   -2.1911


   p(1) is the slope and p(2) is the intercept of the linear predictor. You can also obtain regression coefficients using the Basic Fitting UI.

3. Call polyval to use p to predict y, calling the result yfit:

   yfit = polyval(p,x);

   Using polyval saves you from typing the fit equation yourself, which in this case looks like:

   yfit =  p(1) * x + p(2);

4. Compute the residual values as a vector of signed numbers:

   yresid = y - yfit;

5. Square the residuals and total them to obtain the residual sum of squares:

   SSresid = sum(yresid.^2);

6. Compute the total sum of squares of y by multiplying the variance of y by the number of observations minus 1:

   SStotal = (length(y)-1) * var(y);


7. Compute R² using the formula given in the introduction of this topic:

   rsq = 1 - SSresid/SStotal

   rsq =
       0.8707

   This demonstrates that the linear equation 1.5229 * x -2.1911 predicts 87% of the variance in the variable y.

Computing Adjusted R² for Polynomial Regressions

You can usually reduce the residuals in a model by fitting a higher degree polynomial. When you add more terms, you increase the coefficient of determination, R². You get a closer fit to the data, but at the expense of a more complex model, for which R² cannot account. However, a refinement of this statistic, adjusted R², does include a penalty for the number of terms in a model. Adjusted R², therefore, is more appropriate for comparing how different models fit to the same data. The adjusted R² is defined as:

R²_adjusted = 1 - (SS_resid / SS_total)*((n-1)/(n-d-1))

where n is the number of observations in your data, and d is the degree of the polynomial. (A linear fit has a degree of 1, a quadratic fit 2, a cubic fit 3, and so on.)

The following example repeats the steps of the previous example, Example: Computing R2 from Polynomial Fits, but performs a cubic (degree 3) fit instead of a linear (degree 1) fit. From the cubic fit, you compute both simple and adjusted R² values to evaluate whether the extra terms improve predictive power:

1. Create two variables, x and y, from the first two columns of the count variable in the data file count.dat:

   load count.dat
   x = count(:,1);
   y = count(:,2);

2. Call polyfit to generate a cubic fit to predict y from x:

   p = polyfit(x,y,3)

   p =
      -0.0003    0.0390    0.2233    6.2779

   p(4) is the intercept of the cubic predictor. You can also obtain regression coefficients using the Basic Fitting UI.

3. Call polyval to use the coefficients in p to predict y, naming the result yfit:

   yfit = polyval(p,x);

   polyval evaluates the explicit equation you could manually enter as:

   yfit =  p(1) * x.^3 + p(2) * x.^2 + p(3) * x + p(4);

4. Compute the residual values as a vector of signed numbers:

   yresid = y - yfit;

5. Square the residuals and total them to obtain the residual sum of squares:

   SSresid = sum(yresid.^2);

6. Compute the total sum of squares of y by multiplying the variance of y by the number of observations minus 1:

   SStotal = (length(y)-1) * var(y);


7. Compute simple R² for the cubic fit using the formula given in the introduction of this topic:

   rsq = 1 - SSresid/SStotal

   rsq =
       0.9083

8. Finally, compute adjusted R² to account for degrees of freedom:

   rsq_adj = 1 - SSresid/SStotal * (length(y)-1)/(length(y)-length(p))

   rsq_adj =
       0.8945

   The adjusted R², 0.8945, is smaller than simple R², .9083. It provides a more reliable estimate of the power of your polynomial model to predict.

In many polynomial regression models, adding terms to the equation increases both R² and adjusted R². In the preceding example, using a cubic fit increased both statistics compared to a linear fit. (You can compute adjusted R² for the linear fit for yourself to demonstrate that it has a lower value.) However, it is not always true that a linear fit is worse than a higher-order fit: a more complicated fit can have a lower adjusted R² than a simpler fit, indicating that the increased complexity is not justified. Also, while R² always varies between 0 and 1 for the polynomial regression models that the Basic Fitting tool generates, adjusted R² for some models can be negative, indicating that a model that has too many terms.

Correlation does not imply causality. Always interpret coefficients of correlation and determination cautiously. The coefficients only quantify how much variance in a dependent variable a fitted model removes. Such measures do not describe how appropriate your model—or the independent variables you select—are for explaining the behavior of the variable the model predicts.

Fitting Data with Curve Fitting Toolbox Functions

Curve Fitting Toolbox extends core MATLAB functionality by enabling the following data-fitting capabilities:

• Linear and nonlinear parametric fitting, including standard linear least squares, nonlinear least squares, weighted least squares, constrained least squares, and robust fitting procedures

• Nonparametric fitting

• Statistics for determining the goodness of fit

• Extrapolation, differentiation, and integration

• Dialog box that facilitates data sectioning and smoothing

• Saving fit results in various formats, including MATLAB code files, MAT-files, and workspace variables

For more information, see Curve Fitting Toolbox.
