# taylorPrunableNetwork

## Description

A `TaylorPrunableNetwork`

object enables support for pruning of
filters in convolution layers by using first-order Taylor approximation. To prune filters in a
`dlnetwork`

object, first convert it to a
`TaylorPrunableNetwork`

object and then use the associated object
functions.

To prune a deep neural network, you require the Deep Learning Toolbox™ Model Quantization Library support package. This support package is a free add-on that you can download using the Add-On Explorer. Alternatively, see Deep Learning Toolbox Model Quantization Library.

## Creation

### Description

converts a `prunableNet`

= taylorPrunableNetwork(`net`

)`dlnetwork`

object `net`

to a
`TaylorPrunableNetwork`

object. The latter is a different
representation of the same network that is suitable for pruning by using the Taylor
pruning algorithm. If the input network cannot be pruned, this function produces an
error.

converts the network layers specified in `prunableNet`

= taylorPrunableNetwork(`layers`

)`layers`

to a
`TaylorPrunableNetwork`

object that is suitable for pruning by using
the Taylor pruning algorithm. The input `layers`

must be a
`LayerGraph`

object or a `Layer`

array that can be
converted to a `dlnetwork`

object.

### Input Arguments

## Properties

## Object Functions

`forward` | Compute deep learning network output for training |

`predict` | Compute deep learning network output for inference |

`updatePrunables` | Remove filters from prunable layers based on importance scores |

`updateScore` | Compute and accumulate Taylor-based importance scores for pruning |

`dlnetwork` | Deep learning network for custom training loops |

## Examples

## More About

## Algorithms

For an individual input data point in the pruning dataset, you use the `forward`

function to calculate the output of the deep learning network and the
activations of the prunable filters. Then you calculate the gradients of the loss with respect
to these activations using automatic differentiation. You then pass the network, the
activations, and the gradients to the `updateScore`

function. For each prunable filter in the network, the `updateScore`

function calculates the change in loss that occurs if that filter is pruned from the network
(up to first-order Taylor approximation). Based on this change, the function associates an
importance score with that filter and updates the `TaylorPrunableNetwork`

object [1].

Inside the custom pruning loop, you accumulate importance scores for the prunable filters
over all mini-batches of the pruning dataset. Then you pass the network object to the
`updatePrunables`

function. This functions prunes the filters that have the lowest importance scores and hence
have the smallest effect on the accuracy of the network output. The number of filters that a
single call to the `updatePrunables`

function prunes is determined by the
optional name-value argument `MaxToPrune`

, that has a default value of
`8`

.

All these steps complete a single pruning iteration. To further compress your model, repeat these steps multiple times over a loop.

## References

[1] Molchanov, Pavlo, Stephen Tyree, Tero Karras, Timo Aila, and Jan Kautz. "Pruning Convolutional Neural Networks for Resource Efficient Inference." Preprint, submitted June 8, 2017. https://arxiv.org/abs/1611.06440.

## Version History

**Introduced in R2022a**
