# polyshape

2-D polygons

## Description

The `polyshape`

function creates a polygon defined by 2-D
vertices, and returns a `polyshape`

object with properties describing
its vertices, solid regions, and holes. For example, ```
pgon = polyshape([0 0 1
1],[1 0 0 1])
```

creates the solid square defined by the four points (0,1),
(0,0), (1,0), and (1,1).

>> pgon = polyshape([0 0 1 1],[1 0 0 1])

pgon = polyshape with properties: Vertices: [4×2 double] NumRegions: 1 NumHoles: 0

>> plot(pgon)

## Creation

When creating a `polyshape`

object, the input vertices should define
one or more boundaries of a polygon that have no intersections and are properly nested.
Otherwise, the `polyshape`

function automatically alters the input
vertices as needed to create a well-defined polygon.

If you want to create a regular polygon, you can also use the `nsidedpoly`

function. `nsidedpoly`

enables you to
optionally specify parameters such as the center point and side length of the
polygon.

### Syntax

### Description

`pgon = polyshape()`

creates an empty
`polyshape`

object.

`pgon = polyshape(`

creates a
`P`

)`polyshape`

from the 2-D vertices defined in the
*N*-by-2 matrix `P`

, where
*N* is the number of vertices. The first column of
`P`

defines the *x*-coordinates, and the
second column defines the `y`

-coordinates.

`pgon = polyshape(___,`

specifies additional parameters for creating a `Name,Value`

)`polyshape`

object for any of the previous syntaxes.

### Input Arguments

## Properties

## Object Functions

## Examples

## Version History

**Introduced in R2017b**
